Configure your Cell Testing Lab:
Equipment designed for GIGA-Factories, OEMs & Research Centers
Climate Chamber Integrated Cell Tester
High Power Cell Tester
Medium Power Cell Tester
Low Power Cell Tester
Primary Test Equipment
5A Desktop Cell Tester
Auxiliary Input and Output Systems
Advanced High Power Cell Tester
ICT0550
Climate Chamber Integrated Cell Tester
IDEAL FOR: Testing and evaluating cells
MOSTLY USED IN: High Volume Testing , Quality Control, Incoming Goods Inspection
The ICT0550 integrates test instrumentation, climate chambers and cell holders in a single integrated solution.
The ICT0550 ecosystem also contains the equipment and tools for the lab operators to prepare the cells with auxiliary sensors and clamping plates.
PEC’s LifeTest™ software will guide the operators through the logistics processes in the test lab, and give lab managers and supervisors the tools to plan and monitor the test stands.
ACT0550
Advanced High Power Cell Tester
IDEAL FOR: High speed and accuracy demanding testing
MOSTLY USED IN: (H)EV, solar, wind, grid and other energy storage solutions,
R&D, Quality Control, Incoming Goods Inspection
Configurable Testing via an Event Table, off-line on any PC with our LifeTest™ application.
Highly accurate, reliable and flexible real time measurements through
80 channels of 5V / 50A per test rack.
Standard ACT0505 features 4 automatically switched current ranges. Optionally added: analog and digital in- and outputs via the auxiliary I/O modules of 8 slots each (e.g. temperature sensors, voltage inputs, pressure sensors, digital output etc.)
Guaranteed accuracy with ultra fast switching between charging and discharging modes.
CT0550
High Power Cell Tester
IDEAL FOR: Testing and evaluating cells
MOSTLY USED IN: High Volume Testing , Quality Control, Incoming Goods Inspection
Configurable Testing via an Event Table, off-line on any PC with our LifeTest™ application.
Highly accurate, reliable and flexible measurements through 10 independent channels of 5V / 5A per unit.
Standard ACT0505 features 3 automatically switched current ranges. Optionally added: analog and digital in- and outputs via the auxiliary I/O modules of 8 slots each (e.g. temperature sensors, voltage inputs, pressure sensors, digital output etc.)
Guaranteed accuracy with ultra fast switching between charging and discharging modes.
CT0510
Medium Power Cell Tester
IDEAL FOR: High volume testing multi-layer pouch, 18650, 21700 or 46XXX cells
MOSTLY USED IN: Cell development and QC labs, Cell Formation,
Quality Control, Lifecycle testing
Configurable Testing via an Event Table, off-line on any PC with our LifeTest™ application.
Individually controlled channels and 8-cell boards for high-volume testing.
High Channel Density via Regenerative Power Supplies.
1024 channels of 5V, 10A per rack. Optionally added: analog and digital in- and outputs via the auxiliary I/O modules of 8 slots each (e.g. temperature sensors, voltage inputs, pressure sensors, digital output etc.)
Minimum pulsing width of 10 msec for current, voltage, power and resistive based loads. Guaranteed accuracy with ultra fast switching between charging and discharging modes.
CT0501
Low Power Cell Tester
IDEAL FOR: Low power tester for high volume testing R&D coin, single layer pouch or 18650 cells
MOSTLY USED IN: Cell development and QC labs, Cell Formation,
Quality Control, Lifecycle testing
Configurable Testing via an Event Table, off-line on any PC with our LifeTest™ application.
Individually controlled channels and 8-cell boards for high-volume testing.
High accuracy and speed via Linear Power Mosfets.
1024 channels of 5V, 500m A and 3 selectable current ranges per rack. Optionally added: analog and digital in- and outputs via the auxiliary I/O modules of 8 slots each (e.g. temperature sensors, voltage inputs, pressure sensors, digital output etc.)
Minimum pulsing width of 10 msec for current, voltage, power and resistive based loads. Guaranteed accuracy with ultra fast switching between charging and discharging modes.
BDT1012
Primary Test Equipment
IDEAL FOR: testing and evaluating batteries according to IEC60086-1/2
MOSTLY USED IN: R&D, Quality Control, Incoming Goods Inspection
Expandable channel capacity by adding extra testers in a fieldbus (CAN) network.
Capacity per controller: more than 5.000 batteries simultaneously and independently.
Easy-to-Setup compatibility with any PC.
High accuracy, reliability and flexibility with a dynamic electronic load on
24 fully independent channels.
Typical, continuous or intermittent lifecycle and application tests can be performed with pulses of 10msec.
Compliance to the latest standards in electronics and informatics.
Guaranteed data-integrity during a power-failure, network or pc-controller breakdown.
ACT0505
5A Desktop Cell Tester
IDEAL FOR: Testing and evaluating cells and batteries according to IEC285
MOSTLY USED IN: R&D, Formation, Ranking, Quality Control, Incoming Goods Inspection
Configurable Testing via an Event Table, off-line on any PC with our LifeTest™ application.
Highly accurate, reliable and flexible measurements through 10 independent channels of 5V / 5A per unit.
Standard ACT0505 features 3 automatically switched current ranges. Optionally added: analog and digital in- and outputs via the auxiliary I/O modules of 8 slots each (e.g. temperature sensors, voltage inputs, pressure sensors, digital output etc.)
Guaranteed accuracy with ultra fast switching between charging and discharging modes.
AIOS
Auxiliary Input and Output Systems
IDEAL FOR: Advanced battery and module Testing
MOSTLY USED IN: Monitor individual cell voltages and cell temperatures
Control relais with digital in-and-out-puts
Use data from Auxiliary Input and Output Systems as end-conditions or triggers in your test profile
